AS/NZS 4331.1 Flange Specifications
| NOMINAL PIPE SIZE |
FLANGE OUTSIDE DIAMETER |
INSIDE DIAMETER |
THICKNESS OF FLANGE |
BOSSED SOW |
WELD NECK |
PITCH CIRCLE DIAMETER |
BOLT HOLE DIAMETER |
NUMBER OF BOLT HOLES |
|
OD |
ID |
T |
L |
L1 |
PCD |
H |
# |
|
95 |
22.3 |
5 |
15 |
27 |
67 |
14 |
4 |
|
100 |
27.6 |
5 |
16 |
27 |
73 |
14 |
4 |
|
115 |
34.5 |
5 |
16 |
27 |
83 |
14 |
4 |
|
120 |
|
6 |
17 |
31 |
87 |
14 |
4 |
|
135 |
49.5 |
6 |
19 |
35 |
98 |
14 |
4 |
|
150 |
61.9 |
8 |
21 |
37 |
114 |
18 |
4 |
|
165 |
74.6 |
8 |
24 |
40 |
127 |
18 |
4 |
|
185 |
90.6 |
10 |
26 |
45 |
146 |
18 |
4 |
|
205 |
103.3 |
10 |
27 |
45 |
165 |
18 |
4 |
|
215 |
116.0 |
10 |
29 |
51 |
178 |
18 |
4 |
|
255 |
143.7 |
13 |
32 |
57 |
210 |
18 |
8 |
|
280 |
170.6 |
13 |
32 |
61 |
235 |
18 |
8 |
|
335 |
221.4 |
13 |
35 |
64 |
292 |
18 |
8 |
|
370 |
249.0 |
16 |
41 |
73 |
324 |
18 |
8 |
|
405 |
276.3 |
16 |
43 |
80 |
356 |
22 |
8 |
|
455 |
327.1 |
19 |
48 |
89 |
406 |
22 |
12 |
|
525 |
359.1 |
22 |
|
95 |
470 |
26 |
12 |
|
550 |
408.0 |
22 |
|
|
495 |
26 |
12 |
|
580 |
410.4 |
22 |
|
|
521 |
26 |
12 |
|
640 |
461.7 |
25 |
|
|
584 |
26 |
12 |
|
705 |
513.0 |
29 |
|
|
641 |
26 |
16 |
|
735 |
|
29 |
|
|
673 |
26 |
16 |
|
760 |
564.3 |
29 |
|
|
699 |
30 |
16 |
|
825 |
615.9 |
32 |
|
|
756 |
30 |
16 |
|
910 |
717.5 |
35 |
|
|
845 |
30 |
20 |
|
995 |
768.3 |
41 |
|
|
927 |
33 |
20 |
|
1060 |
819.1 |
41 |
|
|
984 |
36 |
20 |
|
1090 |
869.9 |
44 |
|
|
1016 |
36 |
20 |
|
1175 |
920.7 |
48 |
|
|
1092 |
36 |
24 |
|
1255 |
1022.3 |
51 |
|
|
1175 |
36 |
24 |
|
1335 |
1073.1 |
54 |
|
|
1251 |
36 |
28 |
|
1490 |
1225.5 |
60 |
|
|
1410 |
36 |
32 |
|
