Leaders among the leading ISO 7005-1 Flange manufacturers.

Pipes & Tubes

Flanges

we are widely recognized as a worldwide inventory leader for ISO 7005-1 Flange

we make use of latest technology to manufacture a wide range of ISO 7005-1 Flange.

Content:

» ISO 7005-1 Flange Specifications

» ISO 7005-1 Flange Packaging

» ISO 7005-1 Flange Prices List

» ISO 7005-1 Flange Inventory

Satellite Metals & Tubes's core business is the production of ISO 7005-1 Flange for the water and gas distribution network, sewage treatment and fire protection. Furthermore, Satellite Metals & Tubes has built up strong brands supplying valves and controls for water treatment, dams & reservoirs, HVAC, chemical processing, marine and other industrial sectors. Satellite Metals & Tubes products are designed to the major international standards and are sold in more than countries worldwide. When dealing with the Satellite Metals & Tubes expect quality, reliability, functionality and long lifetime in service.

Satellite Metals & Tubes has not just veryfied the design but we also work in the optimization in order to obtain the best possible and most competitive solution in both the technical and commercial aspects.

In that year, the company began manufacturing stainless steel and established divisions for bright bars and for flanges and forging, and started exporting bright bars. Almost every year since then Satellite Metals & Tubes has added a type of ISO 7005-1 Flange to its range, including sections and profiles, fasteners, wire and wire rods.

ISO 7005-1 Flange Specifications

Nom. Dia		PN 6					PN 10					PN 16
DN	NPS	D	d	d1	Bolt	No. of bolts	D	d	d1	Bolt	No. of bolts	D	d	d1	Bolt	No. of bolts
DN 40	1 1/2	130	110	14	M12	4	150	110	18	M16	4	150	110	18	M16	4
DN 50	2	140	110	14	M12	4	165	125	18	M16	4	165	125	18	M16	4
DN 65	2 1/2	160	130	14	M12	4	185	145	18	M16	4	185	145	18	M16	4
DN 80	3	190	150	18	M16	4	200	160	18	M16	8	200	160	18	M16	8
DN 100	4	210	170	18	M16	4	220	180	18	M16	8	220	180	18	M16	8
DN 125	5	240	200	18	M16	8	250	210	18	M16	8	250	210	18	M16	8
DN 150	6	265	225	18	M16	8	285	240	22	M20	8	285	240	22	M20	8
DN 200	8	320	280	18	M16	8	340	295	22	M20	8	340	295	22	M20	12
DN 250	10	375	335	18	M16	12	395	350	22	M20	12	400	355	26	M24	12
DN 300	12	440	395	22	M20	12	445	400	22	M20	12	455	410	26	M24	12
DN 350	14	490	445	22	M20	12	505	460	22	M20	16	520	470	26	M24	16
DN 400	16	540	495	22	M20	16	565	515	26	M24	16	580	525	30	M27	16
DN 450	18	595	550	22	M20	16	615	565	26	M24	20	640	585	30	M27	20
DN 500	20	645	600	22	M20	20	670	620	26	M24	20	715	650	33	M30	20
DN 600	24	755	705	26	M24	20	780	725	30	M27	20	840	770	36	M33	20
DN 700	28	860	810	26	M24	24	895	840	30	M27	24	910	840	36	M33	24
DN 800	32	975	920	30	M27	24	1015	950	33	M30	24	1025	950	36	M36	24
DN 900	36	1075	1020	30	M27	24	1115	1050	33	M30	28	1125	1050	39	M36	28
DN 1000	40	1175	1120	30	M27	28	1230	1160	36	M33	28	1255	1170	42	M39	28

Nom. Dia		PN 25					ANSI150					JIS 5K
DN	NPS	D	d	d1	Bolt	No. of bolts	D	d	d1	Bolt	No. of bolts	D	d	d1	Bolt	No. of bolts
DN 40	1 1/2	150	110	18	M16	4	127	98.4	15.9	1/2	4	120	95	15	M12	4
DN 50	2	165	125	18	M16	4	152.4	120.6	19	5/8	4	130	105	15	M12	4
DN 65	2 1/2	185	145	18	M16	8	177.8	139.7	19	5/8	4	155	130	15	M12	4
DN 80	3	200	160	18	M16	8	190.5	152.4	19	5/8	4	180	145	19	M16	4
DN 100	4	235	190	22	M20	8	228.6	190.5	19	5/8	8	200	165	19	M16	8
DN 125	5	270	220	26	M24	8	254	215.9	22	3/4	8	235	200	19	M16	8
DN 150	6	300	250	26	M24	8	279.4	241.3	22	3/4	8	265	230	19	M16	8
DN 200	8	360	310	26	M24	12	342.9	298.4	22	3/4	8	320	280	23	M20	8
DN 250	10	-	-	-	-	-	406.4	361.9	25	7/8	12	385	345	23	M20	12
DN 300	12	-	-	-	-	-	482.6	431.8	25	7/8	12	430	390	23	M20	12
DN 350	14	-	-	-	-	-	533.4	476.2	28	1	12	480	435	25	M22	12
DN 400	16	-	-	-	-	-	596.9	539.7	28	1	16	540	495	25	M22	16
DN 450	18	-	-	-	-	-	635	577.8	32	1 1/8	16	605	555	25	M22	16
DN 500	20	-	-	-	-	-	698.5	635	32	1 1/8	20	655	605	25	M22	20
DN 600	24	-	-	-	-	-	812.8	749.3	35	1 1/4	20	770	715	27	M24	20
DN 700	28	-	-	-	-	-	927.1	863.6	35	1 1/4	28	875	820	27	M24	24
DN 800	32	-	-	-	-	-	1060.4	977.9	41	1 1/2	28	995	930	33	M30	24
DN 900	36	-	-	-	-	-	1168.4	1085.8	41	1 1/2	32	1095	1030	33	M30	24
DN 1000	40	-	-	-	-	-	1289	1200.2	41	1 1/2	36	1195	1130	33	M30	28

Nom. Dia		JIS 10K
DN	NPS	D	d	d1	Bolt	No. of bolts
DN 40	1 1/2	140	105	19	M16	4
DN 50	2	155	120	19	M16	4
DN 65	2 1/2	175	140	19	M16	4
DN 80	3	185	150	19	M16	8
DN 100	4	210	175	19	M16	8
DN 125	5	250	210	23	M20	8
DN 150	6	280	240	23	M20	8
DN 200	8	330	290	23	M20	12
DN 250	10	400	355	25	M22	12
DN 300	12	445	400	25	M22	16
DN 350	14	490	445	25	M22	16
DN 400	16	560	510	27	M24	16
DN 450	18	620	565	27	M24	20
DN 500	20	675	620	27	M24	20
DN 600	24	795	730	33	M30	24
DN 700	28	905	840	33	M30	24
DN 800	32	1020	950	33	M30	28
DN 900	36	1120	1050	33	M30	28
DN 1000	40	1235	1160	39	M36	28

ISO 7005-1 Flange Packaging

Our packaging focus on every procedure to assure quality,the package we usually take is pack the fittings with environmental poly bags, and then in free fumigation wooden cases or wooden palte. ISO 7005-1 Flange can accept customized package.

ISO 7005-1 Flange Prices List

Forged Flange
US $1-10000 / Piece ( FOB Price)

Forging Flanged Factory Supplier
US $1000-2000 / Metric Ton ( FOB Price)

stainless flange
US $0.1-100 / Piece ( FOB Price)

flange / Flange
US $1-1000 / Piece ( FOB Price)

stainless steel flange
US $0.5-500 / Piece ( FOB Price)

ANSI Stainless Steel Welding Neck Flange
US $1-500 / Piece ( FOB Price)

Slip-on Welding Steel Pipe Flange
US $0.1-1000 / Piece ( FOB Price)

Welding Neck Flange
US $1.5-1200 / Piece ( FOB Price)

ANSI Flange
US $1-500 / Piece ( FOB Price)

Flange
US $1-1000 / Ton ( FOB Price)

galvanized pipe flange
US $700-1100 / Ton ( FOB Price)

DIN forged flange 2534
US $700-900 / Ton ( FOB Price)

ISO 7005-1 Flange Inventory
