Satellite Metals & Tubes's core business is the production of Short Stubend for the water and gas distribution network, sewage treatment and fire protection. Furthermore, Satellite Metals & Tubes has built up strong brands supplying valves and controls for water treatment, dams & reservoirs, HVAC, chemical processing, marine and other industrial sectors. Satellite Metals & Tubes products are designed to the major international standards and are sold in more than countries worldwide. When dealing with the Satellite Metals & Tubes expect quality, reliability, functionality and long lifetime in service.
Satellite Metals & Tubes has not just veryfied the design but we also work in the optimization in order to obtain the best possible and most competitive solution in both the technical and commercial aspects.
In that year, the company began manufacturing stainless steel and established divisions for bright bars and for flanges and forging, and started exporting bright bars. Almost every year since then Satellite Metals & Tubes has added a type of Short Stubend to its range, including sections and profiles, fasteners, wire and wire rods.
Short Stubend Specifications
Size : 1/2"NB TO 48"NB IN
Schedule: SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : End Cap ,Stub End
Material Type:
Stainless Steel
ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel
ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel
ASTM A420 WPL3 / A420WPL6
Alloy Steel
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Duplex Steel
ASTM A 815 UNS NO S 31803 , S 32205.
Nickel Alloy
ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 )
VALUE ADDED SERVICES
- Hot Dip Galvanizing
- Epoxy Coating
- Electro polish
TEST CERTIFICATE
Mill Test Certificate as per EN 10204 / 3.1B
| Nominal Pipe Size (NPS) |
Outside Diameter at Bevel (O/D) |
Long Pattern Length ''F'' |
Short Pattern 'F' |
Radius of Follet 'R' |
Dia of Lap 'G' |
Length 'E' |
Limiting Wall Thk for Length 'E' |
Length 'E1' |
| 1/2'' |
21.3 |
76.0 |
51 |
3 |
35 |
25 |
4.57 |
25 |
| 3/4'' |
26.7 |
76.0 |
51 |
3 |
43 |
25 |
3.81 |
25 |
| 1'' |
33.4 |
102.0 |
51 |
3 |
51 |
38 |
4.57 |
38 |
| 1 ¼'' |
42.2 |
102.0 |
51 |
5 |
64 |
38 |
4.83 |
38 |
| 1 ½'' |
48.3 |
102.0 |
51 |
6 |
73 |
38 |
5.08 |
38 |
| 2'' |
60.3 |
152.0 |
64 |
8 |
92 |
38 |
5.59 |
44 |
| 2 ½'' |
73.0 |
152.0 |
64 |
8 |
105 |
38 |
7.11 |
51 |
| 3'' |
88.9 |
152.0 |
64 |
10 |
127 |
51 |
7.62 |
64 |
| 3 ½'' |
101.6 |
152.0 |
76 |
10 |
140 |
64 |
8.13 |
76 |
| 4'' |
114.3 |
152.0 |
76 |
11 |
157 |
64 |
8.64 |
76 |
| 5'' |
141.3 |
203.0 |
76 |
11 |
186 |
76 |
9.65 |
89 |
| 6'' |
168.3 |
203.0 |
89 |
13 |
216 |
89 |
10.92 |
102 |
| 8'' |
219.1 |
254.0 |
102 |
13 |
270 |
102 |
12.7 |
127 |
| 10'' |
273.0 |
254.0 |
127 |
13 |
324 |
127 |
12.7 |
152 |
| 12'' |
323.8 |
305.0 |
152 |
13 |
381 |
152 |
12.7 |
178 |
| 14'' |
355.6 |
305.0 |
152 |
13 |
413 |
165 |
12.7 |
191 |
| 16'' |
406.4 |
305.0 |
152 |
13 |
470 |
178 |
12.7 |
203 |
| 18'' |
457.0 |
305.0 |
152 |
13 |
533 |
203 |
12.7 |
229 |
| 20'' |
508.0 |
305.0 |
152 |
13 |
584 |
229 |
12.7 |
254 |
| 22'' |
559.0 |
305.0 |
152 |
13 |
641 |
254 |
12.7 |
254 |
| 24'' |
610.0 |
305.0 |
152 |
13 |
692 |
267 |
12.7 |
305 |
