Leaders among the leading Thread fittings Adapter manufacturers.




» Forged Type Threaded    Fittings
» Thread fittings 90° Elbow
» Thread fittings 45° Elbow
» Thread fittings Tee
» Thread fittings Cross
» Thread fittings Full Coupling
» Thread fittings Half Coupling
» Thread fittings Reducing    Coupling
» Thread fittings Pipe Cap
» Thread fittings Hex Head    Bushing
» Thread fittings Hex Head    Plug
» Thread fittings Square Head    Plug
» Thread fittings Round Head    Plug
» Thread fittings Union
» Thread fittings Hex Nipple
» Thread fittings Street Elbow
» Thread fittings Bull Plug
» Thread fittings Boss
» Thread fittings Swage Nipple
» Thread fittings Pipe Nipple
» Thread fittings Adapter
» Thread fittings Uniom (Male    x Female)
» Thread fittings Branch    Outlet
» Thread fittings 90° Elbow    Outlet
» Thread fittings 45° Lateral    Outlet
» Thread fittings Lateral    Outlet
» Thread fittings Nipple    Branch Outlet
» Forged Type Socket weld    Fittings






we are widely recognized as a worldwide inventory leader for Thread fittings Adapter

we make use of latest technology to manufacture a wide range of Thread fittings Adapter.

Content:

» Thread fittings Adapter Specifications

» Thread fittings Adapter Packaging

» Thread fittings Adapter Prices List

» Thread fittings Adapter Inventory

Satellite Metals & Tubes's core business is the production of Thread fittings Adapter for the water and gas distribution network, sewage treatment and fire protection. Furthermore, Satellite Metals & Tubes has built up strong brands supplying valves and controls for water treatment, dams & reservoirs, HVAC, chemical processing, marine and other industrial sectors. Satellite Metals & Tubes products are designed to the major international standards and are sold in more than countries worldwide. When dealing with the Satellite Metals & Tubes expect quality, reliability, functionality and long lifetime in service.

Satellite Metals & Tubes has not just veryfied the design but we also work in the optimization in order to obtain the best possible and most competitive solution in both the technical and commercial aspects.

In that year, the company began manufacturing stainless steel and established divisions for bright bars and for flanges and forging, and started exporting bright bars. Almost every year since then Satellite Metals & Tubes has added a type of Thread fittings Adapter to its range, including sections and profiles, fasteners, wire and wire rods.

Thread fittings Adapter Specifications

DN Nominal Pipe Size Center-to
-End
Elbows,
Tees,
Crosses, A
Center-to-
End 45
deg Elbow, C
Outside
Diameter
of Band, H
Min.
Wall
Thickness, G
Min
Length
of
Thread [Note (1)]
2000 3000 6000 2000 3000 6000 2000 3000 6000 2000 3000 6000 B L2
6 1/8 21 21 25 17 17 19 22 22 25 3.18 3.18 6.35 6.4 6.7
8 1/4 21 25 28 17 19 22 22 25 33 3.18 3.30 6.60 8.1 10.2
10 3/8 25 28 33 19 22 25 25 33 38 3.18 3.51 6.98 9.1 10.4
15 1/2 28 33 38 22 25 28 33 38 46 3.18 4.09 8.15 10.9 13.6
20 3/4 33 38 44 25 28 33 38 46 56 3.18 4.32 8.53 12.7 13.9
25 1 38 44 51 28 33 35 46 56 62 3.68 4.98 9.93 14.7 17.3
32 1 1/4 44 51 60 33 35 43 56 62 75 3.89 5.28 10.59 17.0 18.0
40 1 1/2 51 60 64 35 43 44 62 75 84 4.01 5.56 11.07 17.8 18.4
50 2 60 64 83 43 44 52 75 84 102 4.27 7.14 12.09 19.0 19.2
65 2 1/2 76 83 95 52 52 64 92 102 121 5.61 7.65 15.29 23.6 28.9
80 3 86 95 106 64 64 79 109 121 146 5.99 8.84 16.64 25.9 30.5
100 4 106 114 114 79 79 79 146 152 152 6.55 11.18 18.67 27.7 33.0


Nickel Alloy
ASTM / ASME SB 564 UNS 2200 ( NICKEL 200 ), UNS 4400 (MONEL 400 ), UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 ) ASTM / ASME SB 160 UNS 2201 (NICKEL 201 ) ASTM / ASME SB 472 UNS 8020 ( ALLOY 20 / 20 CB 3 )
Copper Alloy
ASTM / ASME SB 61 UNS NO. C 92200 & ASTM / ASME SB 62 UNS NO. C 83600.
ASTM / ASME SB 151 UNS NO. 70600, 71500, C 70600 ( CU -NI- 90/10), C 71500 ( CU -NI- 70/30), ASTM / ASME SB 152 UNS NO C 10100, C 10200, C 10300, C 10800, C 12000, C 12200.
Stainless Steel
ASTM / ASME SA 182 F 304, 304L, 304H, 309H, 310H, 316, 316H, 316L, 316 LN, 317, 317L, 321, 321H, 347, 347 H.
Duplex Steel
ASTM / ASME SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61.
Carbon Steel
ASTM / ASME A 105.
ASTM / ASME A 350 LF 2.
Alloy Steel
ASTM / ASME A 182 GR F 5, F 9, F 11, F 12, F 22, F 91.



Thread fittings Adapter Packaging





Our packaging focus on every procedure to assure quality,the package we usually take is pack the fittings with environmental poly bags, and then in free fumigation wooden cases or wooden palte. Thread fittings Adapter can accept customized package.

Thread fittings Adapter Prices List

ppr thread pipe fitting
US $0.02-10 / Unit ( FOB Price)

stainless steel thread pipe fittings hose nipple CE Approved
US $0.1-20 / Piece ( FOB Price)

pvc thread fitting BS4346
US $0.031-0.046 / Piece ( FOB Price)

High quality stainless steel pipe thread fittings
US $0.1-0.12 / Piece ( FOB Price)

stainless steel thread fitting
US $0.1-20 / Piece ( FOB Price)

Outlet Black and Galvanized Malleable Iron Thread Fitting/Iron
US $0.5-5 / Piece ( FOB Price)

cast rion union rubber thread fitting
US $30-798 / Set ( FOB Price)

90 degree elbow pipe fitting thread fitting
US $0.1-2 / Piece ( FOB Price)

3000# forged steel thread fittings
US $0.1-50 / Piece ( FOB Price)

pp thread fitting
US $0.3-10.98 / Piece ( FOB Price)

nickel plating BSP thread fittings
US $0.30-1.00 / Piece ( FOB Price)

SS304 Stainless Steel Thread Fittings
US $2-10 / Piece ( FOB Price)

Thread fittings Adapter Inventory
